Key Features
-
Dual Application – Perfect for both FPV drones and fixed-wing aircraft. -
45A Continuous Current – Stable performance even under high load conditions. -
Adjustable BEC (5.8V / 8.2V) – Flexible setup for different flight control systems. -
High Efficiency. Fast Response – Smooth throttle curve ensures precise control. -
Aluminum Heat Sink Design – Excellent cooling and extended component life. -
Compact & Lightweight – Easy to install and optimized for aerodynamic efficiency.
Why Pilots Choose GT45A
-
Consistent. reliable output with integrated protection functions. -
Perfect match for high-speed FPV wings and F2C/F3E/F5D racing aircraft. -
Provides smooth throttle feel. high efficiency. and superior reliability.
🔩 Recommended Combo
-
GT2306 FPV Wing Motor + GT45A ESC -
Designed for F2C / F3E / F5D fixed-wing racing aircraft. -
Supports 2S–6S LiPo batteries. -
Delivers ultra-fast throttle response and stable current output. -
Ideal for FPV racing. long-range. and high-speed applications.
| Specifications | Details |
| Model | GT45A |
| Continuous Current | 45A |
| Maximum Current | 55A |
| Supported Voltage | 2-6S Lipo |
| BEC Output | 5.8V 3A / 8.2V 3A (Switchable) |
| ESC Weight | 16g (25g with packaging) |
| ESC Size | 33 x 15 x 8.8mm |
| Motor Wire | 100mm-16AWG / 3.5mm Banana Plug (Female) |
| Power Cord | 150mm-16AWG / XT30U-M Plug |
| Signal Wire | 200±10mm |
| Programming | AM LINK / Windows Run |
| PWM Frequency | 50-400Hz |
