VELOX V3115: The Reliable Muscle for Your Cinematic Vision
The T-Motor VELOX V3115 is the definitive choice for professional aerial cinematographers. Designed to bridge the gap between power and precision. this motor is optimized for 8 to 11-inch cinematic platforms. Whether you are building a nimble 8-inch chase drone or a heavy-duty 11-inch X8 rig. the V3115 provides the consistent. rock-solid propulsion required for “single-take” recording.
Built with the same DNA that achieved a Guinness World Record. the V3115 uses Titanium Alloy shafts and Japanese EZO bearings to minimize noise and maximize smoothness. Its wide 4-12S compatibility means you can tune your setup for either extreme efficiency or explosive speed. making it the most versatile motor in its class
Recommended Setup
-
Propellers: T-MOTOR T8.5 9.5 10.5 propeller (Max efficiency)
-
ESC: T-Motor V70A SE 4-in-1 Stack / TMOTOR Flame 60A / F60A MINI
-
Drones: Professional 8-11 inch Cinematic / Heavy Lift Platforms (X4 & X8)
-
Battery: 4S – 12S LiPo (Match KV to voltage for optimal performance)
Specifications
-
KV Options: 400KV / 640KV / 900KV / 1050KV
-
Configuration: 12N14P
-
Stator Dimensions: 31 x 15 mm
-
Shaft Diameter: IN: 6mm / OUT: M6
-
Weight (incl. cable): 116.3g (900KV/1050KV) / 115.4g (400KV/640KV)
-
Internal Resistance: $38text{m}Omega$ (1050KV) / $45text{m}Omega$ (900KV) / $114text{m}Omega$ (640KV) / $183text{m}Omega$ (400KV)
-
Peak Current (60s): 63.6A (1050KV) / 51.1A (900KV) / 44.4A (640KV) / 33A (400KV)
-
Max Power (60s): 1521W (1050KV) / 1219W (900KV) / 1111W (640KV) / 1530W (400KV)
Specification
Packing List
-
1x VELOX V3115 Motor
-
1x M6 Prop Nut
-
1x Screw Set (M3*8)
-
1x Washer / O-ring set
| KV | 1050, 400, 640, 900 |
|---|
